Outdoor ground-recessed light
Product Details
FEATURES
ØShallow-depth inground design – Compact structure that integrates seamlessly into various ground installations.
ØRobust die-cast aluminum housing – Durable construction with efficient heat dissipation for long-term performance.
ØMultiple size options – Available in various sizes to suit different spatial requirements.
ØWide range of optical options – Supports both accent and wide-area illumination.
ØPremium LED light source – High-quality Cree mono-color LEDs with multiple lumen outputs.
ØDrive-over rated applications – Suitable for indoor and outdoor drive-over areas, including public and landscape spaces.
ØIP67 protection rating – Fully dust-tight and water-resistant, ideal for demanding outdoor and inground applications.
Product Specs:
| Model No. | EM6012-00 | EM6015-00 | EM6018-00 | EM6021-00 |
| Power | 12W 6*1~2W | 12W 6*1~2W | RGB 3in1 6*3W | RGBW 4in1 6*4W |
| CCT | 1700K~6500K R/G/B/O/Y/I/V | RGB | RGBW W=2700~5000K | |
| Dimming type | ON&OFF/DMX/Dali | ON&OFF | DMX512 Built-in DMX512 External | |
| Beam Angle | 15/25/30/40° | 25/30/40/60/80/120° | ||
| LED Brand | COB/CREE/OSRAM/BRIDGELUX | |||
| Input voltage | 12/24/48Vdc | 100/220Vac | 5/12/24Vdc | |
| IP Rating | 67 | |||
| Cutout | Φ130 | |||
● Due to the different Voltage of lighting fixture, please select the appropriate LED driver based upon the technical specification.
● Installation must be done by professionals.
● Please ensure the power has been cut off before installation in order to prevent the electric shock.
● This product should be installed together with fuse and maintenance should be done by the professional.
● The lamp waste could not be treated as the normal rubbish and should be returned and make use of the normal parts.
● Please consult the authorized department or retailers for returned advice.
Warranty:
This product has a warranty period of 5 Years. Warranties may be available on certain products as indicated in the product description. Warranties are valid from the date of purchase.The warranty is invalid in the case of improper use, installation, tampering, removal of the Q.C. date label or installation in an improper working environment. Should this product fail during the warranty period it will be replaced free of charge subject to the correct installation of the original product and subsequent return of the faulty unit. Emilux does not accept responsibility for any installation costs associated with the replacement of this product and Emilux reserves the right to alter specifications without prior notice.
